ماژول دوربین رزبری پای 5 مگا پیکسل OV5647

Camera Raspberry, 1080P HD 500W Mini Infrared Night Version Camera Module with OV5647 Sensor for Raspberry Pi.

The OV5647 5MP 1080P IR-Cut Camera for Raspberry Pi 3 and 4 with Manual Day Night Mode Switching is a custom designed add-on for Raspberry Pi. It attaches to Raspberry Pi by way of one of the small sockets on the board upper surface. This uses the dedicated Raspberry Pi’s onboard CSI interface, designed especially for interfacing with cameras.The camera supports night vision. It is compatible with all revisions of the Pi. Powered with a 5-megapixel OV5647 sensor, its best resolution is 1080p.

Specification

Sensor Type: 1/4 “
Focal length: 1.67 mm
Max. Length: 16.62 mm
Optical FOV (D): 160 °.
Optical FOV (H): 122 °.
Optical FOV (V): 89.5 °.
Chief Ray Angle: <12 °
Resolution: 5 MPixel 1080p
Image resolution: 2592 x 1944
CCD: CMOS
Power requirement: 96 mA
Standby: 20 µA
Working temperature range: 0 ° C to +50 ° C
Temperature range max .: -30 ° C to +70 ° C
Output format: 8- / 10-bit RAW RGB data
Focus: manual

Frame rate
720p @ 60 fps
1080p @ 30 fps
Full @ 15 fps
VGA @ 90 fps
960p @ 45 fps

این دوربین برای تصویربرداری در تاریکی مناسب میباشد. برای کارکرد بهتر دوربین دید در شب میتوانید raspberry PI camera ,light را خریداری کرده و بر روی دوربین نصب کنید.
