ماژول وای فای ESP8266 ESP-07

ویژگی ها

• محدوده ولتاژ تغذیه: 3 ~ 3.6 ولت
• استاندارد : 802.11B/G/N
• فرکانس: Wi-Fi 2.4 GHz, support WPA/WPA2
• پروتکل ارتباطی: UART/SPI/I2C/ Remote Contorl
• نوع آنتن: سرامیکی
• محدوده دمای کاری: -40 ~ 125 درجه ی سانتی گراد
• ماکزیمم دمای لحیم کاری :260 درجه ی سانتی گراد

کاربردها

• اینترنت اشیا
• خانه هوشمند
• کنترل از طریق وای فای
• صنعت هوشمند
• انتقال داده به صورت ریموت

Introduction

ESP8266 is a highly integrated chip designed for the needs of a new connected world. It offers a complete and self-contained Wi-Fi networking solution, allowing it to either host the application or to offload all Wi-Fi networking functions from another application processor.
ESP8266 has powerful on-board processing and storage capabilities that allow it to be integrated with the sensors and other application specific devices through its GPIOs with minimal development up-front and minimal loading during runtime. Its high degree of on-chip integration allows for minimal external circuitry, and the entire solution, including front-end module, is designed to occupy minimal PCB are.

Specification

802.11 b/g/n
Wi-Fi Direct (P2P), soft-AP
Integrated TCP/IP protocol stack
Integrated TR switch, balun, LNA, power amplifier and matching network
Integrated PLLs, regulators, DCXO and power management units
+19.5dBm output power in 802.11b mode
Power down leakage current of <10uA
Integrated low power 32-bit CPU could be used as application processor
SDIO 1.1/2.0, SPI, UART
STBC, 1×1 MIMO, 2×1 MIMO
A-MPDU & A-MSDU aggregation & 0.4ms guard interval
Wake up and transmit packets in < 2ms
Standby power consumption of < 1.0mW (DTIM3)
